phil&teds cocoon genius - Manual (Page 18)

Installation in the vehicle /17
Seatbelt Installation in
the vehicle
5.1Rearward facing installation in the vehicle
for children up to 13 kg
Please do not leave your child unattended in the
child safety seat in the vehicle.
Children weighing less than 9 kg must use the
cocoon genius rear facing. We recommend to use
the cocoon genius rearward facing until your child
reach a body weight of 13 kg.
The cocoon genius when rear facing must be in
sleeping position (position 5) (see 4.2).
To secure the child seat rearward facing using the
3-point belt of your vehicle proceed as follows:
• Place the cocoon genius rearward facing
in your car. Pull out all the belt from the
retractor, pull the belt around the seat and
close the buckle (5-A).
• Push the Seat Shell (5-B), feed the lap
portion of 3-point-belt through the Lap Belt
Guides slot (5-C).
• Thread the diagonal portion of 3-point-belt
around the Central Position for Diagonal
Belt back of the cocoon genius (5-D).
