12 in. COMPOUND MITER SAW
MODEL NO. 137.212390
PARTS LIST FOR SAW SCHEMATIC B
I.D.
Description
Size
QTY
0DTH
CENTER BOLT
1
0H9A
REAR EXTENTION STAY
1
0J6A
FLAT WASHER
φ8*16-2.5
1
0J74
FLAT WASHER
1/4*5/8-3/32 6
0JAZ
WAVE WASHER
WW-6
2
0JPF
HEX. HD. BOLT
M6*1.0-25 3
0JXB
HEX. SOC. SET SCREW
M6*1.0-16
1
0JXG
HEX. SOC. SET SCREW
M8*1.25-16
1
0K2B
HEX. SOC. HD. CAP SCREW
M6*1.0-16
6
0K2L
HEX. SOC. HD. CAP SCREW
M8*1.25-30
3
0K74
CR. RE. TRUSS HD. SCREW
M6*1.0-8 2
0K7L
CR. RE. ROUND WASHER HD. SCREW
M6*1.0-16
2
0KAE
CR. RE. PAN HD. TAPPING SCREW
M5*0.8-10
1
0KD6
CR. RE. PAN HD. SCREW
M4*0.7-8
7
0KDS
CR. RE. PAN HD. SCREW
M5*0.8-40
1
0KDU
CR. RE. PAN HD. SCREW
M6*1.0-12
2
0KDV
CR. RE. PAN HD. SCREW
M6*1.0-16
4
0KMS
HEX. NUT
M6*1.0 T=5
3
0KQW
LOCK NUT
M5*0.8 T=5
1
0KQX
NUT
M6*1.0 T=6
2
0KR4
LOCK NUT
M8*1.25 T=8
1
2258
SPECIAL BOLT
1
2754
WARNING LABEL
1
20S3
LOCKING HANDLE ASS’Y
1
20X5
ASSIST-FENCE
# AW
1
21EW
CR. RE. PAN HD. TAPPING SCREW
M5*12-35
1
25TD
MITER BAR
4
25TE
STOP BLOCK (LEFT)
# 23
1
25TF
STOP BLOCK (RIGHT)
# 23
1
27BU
TABLE INSERT
1
27BV
TABLE INSERT
1
2C8U
KNOB
2
2CD2
COMPRESSION SPRING
1
2DWL
PLUNGER HANDLE
1
2DWP
NEEDLE POINTER
# 23
1
2F76
FENCE
# AW
1
2K8Q
WARNING LABEL
1
2LSZ
VISE ASS’Y
1
2PY0
BASE
# AW
1
2PY2
TABLE
# AW
1
2PY7
EXTENSION WING (LEFT)
# AW
1
2PY8
EXTENSION WING (RIGHT)
# AW
1
2PYB
SLIDE-BAR BLADE GUARD
1
2PYD
SEGMENT HANDLE (REAR)
1
2PYH
SET PLATE
1
2PYQ
SLIDE PLATE
3
2PYR
SUPPORT
1
2QT8
CR. RE. TRUSS HD. ROUND NECK SCREW
M6*1.0-17
2
2QXE
INSTRUCTION MANUAL
1
2QZX
SCALE
1
2QZZ
SCALE
1
2R2R
TRADE-MARK LABEL
1
2R7W
LOCKING HANDLE ASS’Y
1
