ones ` twos
10
a
b
c
c
double kit accessory
This is often purchased separately with
your sport buggy; carton contains the
following bits and bobs
a. 1 x double seat (on frame)
b. 1 x retaining strap (attached to top of
double seat frame)
hinge kit contains
c. 2 x hinges (R and L - when you stand
behind buggy facing forward).
Double kit has a lay-back
setting. To recline:
unzip side zips and
push top of seat
under bar as shown.
Make sure children are clear of buggy before
folding, unfolding or adjusting the buggy.
Avoid injury: watch fi ngers, especially near
main frame hinge. to fold
buggy, whilst holding frame with
palms of hands.
2. Let upper frame drop back. Lift buggy
by cross bar (under seat) ‘c’ . Let front
wheel fold under frame, and parcel
tray concertina.
3. Attach frame lock (use longer of two
frame lock straps when front wheel
attached)
Ensure that you hold the main
frame of buggy when lifting in and
out of car (as shown).
c c
1. Rotate both auto
locks ‘a’ & ‘b’ 180°,
then press them in
toward centre of
a
b
