Fig. 3

Operation Panel

Horizontal Louver Blade

(manual)

Remote Signal Receptor

Caster

Carrying Handle

(both sides)

1.

2.

3.

4.

5.

Upper Air Filter

(behind the grille)

Air Outlet

Power Cord Outlet

Air Intake

Drain Outlet

Exhaust Hose

Air Intake Grille

Bottom Tray Drain Outlet

6.

7.

8.

9.

10.

11.

12.

13.

IDENTIFICATION OF PARTS (CONTINUED)

4

Fig. 2
