\Tow that you have completed
1 V the required connections on
the previous page you are ready to
follow the simple steps shown
below.
Turn the TV ON.
Place the TV’s PIP SOURCE
SELECT control to "ANT B"-
. With FEATURES MENU (4
of 5) on screen, move the RED
highlight with the MENU (M)
^buttons. Then press the
MENU button.
• Press the MENU AT and
MENU (M) buttons to
highlight and select the
ANT B" (»^) item.
Also place the TV's Main
screen PICTURE SOURCE
SELECT control to "ANT A"-
• See the Picture Source option
FEATURES MENU (1 of 5).
Press the STATUS button to
clear the screen when the above
Menu items have been set.
<4>
Press the PIP ON/OFF button
on the remote.
The PIP window should show in
one of the comers of the TV
screen.
Press the SWAP (or t*'^CtlJ )
buttons on the remote to move the
ANT B and ANT A Input pictures
between the PIP window and
Main screen.
Use the Channel Number or CH
AT buttons to select desired
programs for viewing. Program
Sound occurs with the channels
displayed on the Main screen
S m A u r H t : i , i >
Remember, if you see the
■ same picture on the main
screen and in the PIP window,
check to be sure the TV's PIP
Source Select and Main screen
Picture Source select are set for
ANT B and ANT A respectively.
See the following page on how to
operate other PIP features with the
TV’s remote control.
- MAIN SCREEN - - PIP WINDOW -
□ lANT A I
ANTB
AUX
S-VIDEO
MAIN PICTURE SOURCE SELECT SET
TO "ANT A"
BLACK frame around the PIP window appears
when the ANT A Input is on the Main screen.
WHITE frame around the PIP window appears
when the ANT B Input is on the Main screen.
PRESS
SWAP U4
Main Screen is CH 5 fixim ANT A input.
PIP is CH 8 from ANT B input
PRESS
2 TUNER PIP
on remote then
adjust channels
with CHAV or
Number buttons
• Main Screen shows CH 8 from ANT B input.
• PIP is CH 5 from ANT A input.
39
