AV (A
udio
/V
ideo
) I
nput
C
onnection
J
' ! 'he TV’s audio/video input jacks
J. are for direct picture and sound
connections between the TV and a
VCR (or similar device) that has
audio/video output Jacks. Both the
AVI and AV2 Input Jack connections
are shown on this page, but either
one can be connected alone. Follow
the easy steps below to connect your
accessory device to the AVI and AV2
IN Jacks located on the back of the
TV.
M Connect the VIDEO (yellow)
i cable to the VIDEO AV
1
IN (or
AV2 IN) jack on the back of the
TV.
^ Connect the AUDIO (red and
white) cables to the AUDIO (left
and right) AV
1
IN (or AV2 in)
jacks on the rear of the TV.
Connect the VIDEO (yellow)
cable to the VIDEO OUT jack on
the back of the VCR (either one
or two) or accessory device being
used.
Connect the AUDIO (red and
white) cables to the AUDIO (left
and right) OUT jacks on the rear
of the VCR (either one or two) or
accessory device being used.
Turn the VCR (either one or
two) or accessory device and
the TV ON.
Press the AV button to set the
TV to its AVIor AV2 channel.
With either of the VCRs (or
accessory devices) ON and a pre
recorded tape (CD, DVD, etc.)
inserted, press the PUAY button
to view the tape on the television.
%
Back of TV
VCR Two (or accessoiy
device) (Equipped with
Video and Audio Output Jacks)
Ilri.ri l I. ¡/l\ I
Audio and video cables are not sup
plied with the TV, but are available
from Philips or electronics retailers.
