C able B ox C onnections
J
Jf your cable signal uses a cable
1 box or decoder, follow the easy
steps below to complete the connec­
tion.
Cable Box (w/RF In/Outputs):
This connection will be mono.
^ Connect the Cable Company
i supplied cable to the signal
^ IN(put) plug on the back of the
Cable Box.
Using a separate round coaxial
# cable, connect one end to the
ifc OUT(put) (TO TV) plug on the
back of the Cable Ilox.
Connect the other end of the
% round coaxial cable to the 75Q
input on the back of the televi­
sion. Screw it down finger tight.
NOTE: If apphcable, set the OUT­
PUT CHANNEL SWITCH on the
back of the cable box to CH 3 or 4.
Tune the TV to the same channel and
change channels at the cable box. In
some cases, the cable box will auto­
matically tune to either channel 3 or 4,
change channels until the picture
appears.
Cable Box (w/Audio/Video
Outputs):
This connection will supply Stereo
sound.
^ Connect the Cable Comp
supplied cable to t
^ nal IN(put) plug on the back of
npany
ible sig-
Cable Box (w/RF In/Outputs):
Cable Signal IN from the
Cable Company
Round 75Q
Coaxial Cable
Jack Panel Back of TV
Cable Box (w/Audio/Video Outputs):
Cable Signal IN
from the Cable ..:
Company::
O H l D O D D a
Cable Box with Outputs
the Cable Box.
Using a RCA type Video Cable,
end ( “ ' connect one end of the cable to
the Video (or ANT, your cable
box may be labeled differently)
Out jack on the cable box and
the other end to the AVI Video
Input on the TV.
Pá
Connect one end of the Audio
Left and Right Cable to the left
and right Audio Out L & R
jacks on the cable box. Connect
the other end to the AVI Audio L
& R Input jacks on the TV.
NOTE: Use the AV button on the TV
remote control to tune to the AVI
channel for the cable box signal. Once
tuned, change channels at the cable
box, not the television.
Jack Panel Back of TV
