Trough Install

5

Place Trough Middle onto firebox, shown A.

17

Place Trough A and Trough B onto firebox. Make sure Troughs are put in the right direction, shown B

A

B

Trough Middle

Front

Rear

Trough A

Front

Rear

Rear

Front

Trough B

Trough Middle
