Right and Left Shelf Assembly
1 A
To
w
el
B
ar
Right Side Shelf
C
B
1/4-20x3/4” Screw
7mm Flat Washer
Attach two 1/4-20x3/4” screws, 7mm flat washers and 7mm
lock washers through side shelf holes (right shelf ONLY) into
towel bar shown A.
Insert side shelf over screws and washers through bracket
shown B.
Attach one 1/4-20x1-1/2” screw, one 1/4-20x1/2” screw,two
7mm flat washers and two 7mm lock washers at the rear shelf
flange shown C.
Attach three 1/4-20x1/2” screws, 7mm flat washers and 7mm
lock washers to front shelf flange shown D.
Only right shelf shown for assembly, repeat above
steps B-D for left sideburner shelf.
1/4-20x1/2”
7mm Lock
washer washer
screw
1/4-20x1-1/2”
13
ASSEMBLY
7mm Lock Washer
7mm Flat
1/4-20x3/4”
7mm Flat Washer
7mm Lock Washer
1/4-20x1-1/2” Screw
7mm Flat Washer
7mm Lock Washer
1/4-20x1/2” Screw
7mm lock Washer
7mm Flat Washer
1/4-20x1/2” Screw
Tabs into Cut-outs
And Holes over Bulges
D
