CH-175 User Manual 7 2004-09-20/13:36
O
PERATING
I
NSTRUCTIONS
Foreword
The user buttons on this fixture will become “HOT” to the touch after a few minutes of
operation. It is important to set all manual settings within the first few minutes of
operation while the unit is cool to warm.
Operating Modes
The CH-175 can be operated in three ways.
•
A stand-alone mode will listen to sound and run through 16 built in programs.
• Master/Slave mode will allow linking of up to as many units you want in a synchronized light show to
the sound.
•
Can be operated remotely using the CB-FS Footswitch.
Stand Alone
C H A S E S P E E D
Action ™
1. Press the MODE button until the Chase,
blue LED turns on.
2. Adjust the Chase Speed Rotary Knob for
desired chase speed.
Notes ‡
When you first power up the fixture the default setting
will be the Chase mode.
Chase programs will alternate automatically.
A U D I O A C T I V A T E D
Action ™
1. Press the MODE button until the Audio,
green LED turns on.
2. Adjust the Sound Sensitivity Knob for
optimum performance.
Notes ‡
Master/Slave
The Master/Slave mode will allow you to link up to as many units you want in a daisy chain fashion. In
this mode, the first unit in the daisy chain will automatically command all other units following.
Connecting the CH-175 for (Master/Slave) operation does not require any menu or setting selections.
Simply connect each unit in a daisy like fashion using a CH-DIN20 5 pin DIN cable. Only the first unit
in the chain can be controlled by the optional CB-FS footswitch controller.
Continued on the following page
