DacMagic azur
25
D/A converters Dual Wolfson WM8740 24bit DACs
Digital filter Texas Instruments TMS 320VC5501 DSP
upsampling to 24bit 192kHz
Analogue filter 2-Pole Dual Differential Bessel Double Virtual
Earth Balanced
Frequency response 20Hz to 20kHz (±0.1dB)*
THD @ 1kHz 0dBFs <0.001% 24bit
THD @ 1kHz -10dBFs <0.001%
THD @ 20kHz 0dBFs <0.002%
S/N ratio -112dBr
Total correlated jitter <130pS
Crosstalk @ 1kHz < -100dB
Crosstalk @ 20kHz < -90dB
Output impedance <50ohms
Output level (unbalanced) 2.1V rms
Output level (balanced) 4.2V rms (2.1V per phase)
Digital input word widths supported 16-24bit**
Digital input sampling frequencies supported 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
Audio output upsampling Fixed 24bit 192kHz
Dimensions (H x W x D) 52 x 215 x 191mm
(2.0 x 8.6 x 7.6”)
Weight 1.2kg/2.6lbs
* Steep filter disabled
** 16bit for USB
Technical specifications
ENGLISH
