10
Power On/Off
Switches the unit between On and Off.
Source
Press to select between USB playback or Digital Inputs 1 and 2. The corresponding LED will light up
to show which source has been selected.
Filter/Phase Select
Momentarily press to select between three different filter modes: linear phase, minimum phase or
steep (see page 18 for details). The corresponding LED will light up to show which filter has been
selected.
Upsampling DAC
On / Off
Source
Filter / Phase
Lin
Min
48
88.2
96
32
44.1
Digital 1
Digital 2
Incoming Sample Rate
Phase
Steep
DacMagic
1
2
3
1
2
3
4
5
Front panel controls
