The PLANET uses 6 channels with standard DMX 512 protocol. They are listed in the following
table.
CHANNEL
DMX VALUE
DESCRIPTION
0-14
White
15-29
Red
30-44
Yelow
45-59
Orange
60-74
Blue
75-89
Green
90-104
Cyan
105-119
Purple
120-134
Pink
135-149
Light green
150-164
Indigo
165-178
Light blue
179-185
Light blue/ Indigo
186-192
Indigo / Light green
193-199
Light green / Pink
200-206
Pink / Purple
207-213
Purple / Cyan
214-220
Cyan / Green
221-227
Green / Blue
228-234
Blue / Orange
235-241
Orange / Yellow
242-248
Yellow / Red
1
Colour
249-255
Red / White
0-21
Clear (White)
22-43
Gobo 1 (Windmill)
44-65
Gobo 2 (Triangle)
66-87
Gobo 3 (Swirl)
88-109
Gobo 4 (Mult-circle)
110-131
Gobo 5 (Peacock)
132-153
Gobo 6 (Tri-prong)
154-175
Gobo 7 (Eight clows)
176-197
Gobo 8 (Kink)
198-219
Gobo 9 (Twist)
220-241
Gobo 10 (Tri-leaf)
2
Gobo
242-255
Gobo 11 (Pentacle)
0-14
Shutter
15-29
Open
30-250
Strobe adjust from slow to fast (1~ 7 flashes per
second
3
Strobe
251-255
Open
4 Not used
5
Pan
0-255
Pan movement from 0
to 264
0-5
(Tilt movement) Stop
6-120
Tilt movement from slow to fast in clockwise
121-140
(Tilt movement) Stop
6
Tilt
141-255
Tilt movement from slow to fast in anti-clockwise
DMX CONTROL CHANNEL FUNCTIONS
