OmniSistem PR Planet User Manual
Page 13
planet manual.doc
13/14
COMPONENT ORDER CODES
NAME
PART NO.
REMARK
040010006
230V/50Hz
TRANSFORMER
040140004
200V/60Hz
040090014
230V/50Hz
IGNITOR
040090018
200V/60Hz
040070026
230V/250W/3A
BALLAST
040070028
200V/250W/3A
THERMOSTAT
190010035
120
/15A
FAN
030060008
DC12V
LAMP
100050018
MSD250W
CAP
140010036
32µF/AC 450V
MOTOR 1 (COLOUR-WHEEL)
030040023
17HS0002-38L
MOTOR 2 (GOBO WHEEL)
MOTOR 3 (SHUTTER)
030040056
17HS0002-45L
MOTOR 4 (TILT)
MOTOR 5 (PAN)
030040023
17HS0002-38L
IC1
230040093
DIGITAL-SCREEN CHIP
U1~U6
170110001
DRIVER CHIPS
U7
170170039
STABLE-POWER CHIP
U8
170050002
ARITHMETIC AMPLIFIER
CHIP
U9
230040098
MICROPROCESSOR 1
U10
230040087
WATCH DOG CHIP
U11
230040099
MICROPROCESSOR 2
U12
170040002
TTL REVERSION CHIP
U13
170170034
RESET CHIP
U14
170170012
RECEIVING/TRANSMITTING
CHIP
U15
170040032
EEPROM CHIP
