INDEX
SECTION PAGE
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY - MAINS 5
CONTROL CONNECTIONS 5
SETUP OPTIONS – PROJECTOR CONFIGURATION 6
PROJECTOR DMX START ADDRESS 6
DMX CONTROL CHANNEL FUNCTIONS 7
STAND-ALONE MODES – MASTER/SLAVE 7
MAINTENANCE 8
CHANGING THE GOBOS 8
LUBRIFICATION 8
KEEPING THE PROJECTOR CLEAN 9
TROUBLESHOOTING 9
TECHNICAL DATA 10
ELECTRICAL DIAGRAM 11
COMPONENT ORDER CODES 12
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every apparatus is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the
apparatus is in good condition before your installation and use. Should there be any damage caused by transportation, consult
your dealer and do not use the apparatus. Any damage caused by improper use will not be assumed by the manufacturer and /
or dealer.
ACCESSORIES
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
Mounting Bracket (2 PCS)
M8x25 screw for mounting brackets (4 PCS)
Power-cord (1 PCS)
XLR plug (1 PCS)
XLR socket (1 PCS)
Safety cord (1 PCS)
Spare gobos (4 PCS)
This manual (1 PCS)
INTRODUCTION
Thank you for purchasing the PILOT 300, PR-2301.
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future
reference.
The PILOT 300 is an innovative projector with an elegant housing, which is made from high intensity
and heat–resistant complex plastic. PILOT 300 complies to CE norms and standards and uses
international protocol DMX 512. PILOT 300 can be used as a stand-alone unit or linked to a controller,
so it is suitable for many different applications.
PILOT 300 features 9 colours, 7 interchangeable rotating gobos, and an independent adjustable
strobe/shutter, prism effect and remote focus. It can be setup easily via the touch-switches and digital
display screen.
