COMPONENT ORDER CODES – PILOT 300 PR-2301
NO. NAME PART NO. REMARK
040010044 240V, 50/60Hz
040010036 230V, 50/60Hz
040010039 220V, 50/60Hz
1 TRANSFORMER
040010041 200V/60Hz
2 THERMOSTAT 190010065 75℃/10A
3 CAPACITOR 140010018 60µF/370V
040070024 230V/50Hz
040070025 220V/60Hz
4 BALLAST
040070029 200V/60Hz
5 THERMOSTAT 190010054 95℃/10A
040090020 240V/50-60Hz
040090016 230/220V/50-60Hz
6 IGNITOR
040090009 200V/60Hz
7 LAMP 100050023 HTI 300W/DX
8 TOUCH SWITCH 191010028
9 FAN 030069006 DC24V
MOTOR 1 (PRISM ROTATION) MOTOR 030040047 17HS0002-38
MOTOR 2 (PRISM) MOTOR 030040023 42BYGH023-16
MOTOR 3 (FOCUS) MOTOR 030040023 17HS0002-38
MOTOR 4 (GOBO) MOTOR 030040024 17HS0002-03
MOTOR 5 (GOBO ROTATION) MOTOR 030040023 17HS0002-38
MOTOR 6 (COLOR) MOTOR 030040024 17HS0002-03
MOTOR 7 (SHUTTER1) MOTOR 030040023 17HS0002-03
MOTOR 8 (SHUTTER 2) MOTOR 030040024 17HS0002-38
MOTOR 9 (TILT) MOTOR 030040052 23HS0015
MOTOR 10 (PAN) MOTOR 030040053 23HS2029
A1~A7 IC 170050010 DRIVER CHIPS
A8 IC 170110004 DRIVER CHIP
A9 IC 170050001
ARITHMETIC
AMPLIFIER CHIP
A10 170110004 DRIVER CHIP
B1 IC 170040014 TTL LOGICAL CHIP
B2~B7 IC 170170037 D/A REVERSION CHIP
B8 IC 170040014 TTL LOGICAL CHIP
B9~B11 IC 170170037 D/A REVERSION CHIP
B12-B13 IC 170040014 TTL LOGICAL CHIP
C1 IC 170170039
STABLE-VOLTAGE
CHIP
C2 IC 170170012
BUS CHIP FOR
RECEIVING/TRANSMIT
TING
C3 IC 170040033 EEPROM
D1 IC 230040120 MICROPROCESSOR
NOT SHOWN PAN DRIVE BELT 290151217 309-3M-103Z 103 TEETH
NOT SHOWN TILT DRIVE BELT 290151218 HTD420-3M-140Z 140 TEETH
NOTE: You may order all parts of the PILOT 300 besides the table listed above. When ordering please
state the exact name and part no.. Repairs must be carried out by a qualified technician.
