COMPONENT ORDER CODES
NAME PART NO. REMARK
TRANSFORMER 040050003 230V50Hz/120V60Hz
THERMOSTAT 190010054 95℃/10A
FAN 030060008 DC12V
LAMP 100040051 EFR 15V/150W
RELAY 192010018
BRIDGE 150050012 8A/1000V
(COLOR/GOBO) MOTOR1 030040051 42BYGH036-10A
(MIRROR PAN) MOTOR2
(MIRROR TILT) MOTOR3 030040050 42BYGH036-09A
OPTICAL-COUPLE 171000008 MOC3022
IC1 230040119
MICROPROCESSOR
U1~U3 170110002 DRIVER CHIPS
U4 170170034 RESET CHIP
U5 230040087 SPECIAL CHIP
U6 170170032 BUS CHIP FOR
RECEIVING/TRANSMITTING
U7 170040001 TTL CHIP
U8 170050002 ARITHMETIC AMPLIFIER CHIP
