TROUBLESHOOTING
PROBLEM RESOURCE
The projector does not start Check the fuse on the socket is blown or not.
Check if the lamp is good or not.
The projector switches on but does not
answer to commands Check setting the DIP switch is correct.
Check the XLR cable is good.
The projector only functions
intermittently Check the fan is working and not dirty.
The beam appears dim Check the lamp is not at the end of its life.
Check the optics and anti-heat glass are clean.
Projection with halo Carefully clean the lamp, the optical group lenses and
anti-heat glass.
Defecting projection Check the lenses are not broken.
Remove dust or grease stored on lenses.
TECHNICAL DATA
Power supply: 240V, 230V, 220V, 200V, 120V, 100V AC 50/60Hz To order
Power consumption: 180W at 220V
Lamp: EFR 15V/150W
Channels: 4 channels
Control signal: Standard DMX 512
Control mode: Sound activation / Controller / Remote Controller
Running mode: Stand-Alone mode / Master/Slave synchro mode / Controller mode
Colours / Gobos: 11 one-colour + 2 double-colour + 1 four-colour + white and rainbow
effect / 14 gobos + clear
Mirror movement: Pan movement 175°, Tilt movement 80°
Shutter/Strobe: Shutter on gobo wheel for blackout and strobe, adjustable from 1~7 F.P.S.
Beam angle: 14.6°
Net weight: 6kg
Others: Auto thermal cut-off / Adjustable lamp brightness / Manual adjustable focus
/ Auto switch off the lamp after 8 seconds of shutter
