DMX START ADDRESS SETTING TABLE FOR 3 ROTARY DIP SWISHES
The following table lists the address codes setting from 1 to 80 lumanaires. (Actually, the 3 rotary
DIP switches may set address of 167 luminaires in all.) The setting way is to turn the 3 tuning-
wheel switches to let the arrows of the switches allign respectively to values as shown in the
following table.
The calculating formula is: 6 x (sequential number-1) + 1=ABC
Notes: A means HUNDREDS, B means TENS, C means UNITS
Example: If you want to set the luminaire’s No. 15 address code, you should calcalate the result
as following: 6x(15-1)+1=085. So the UNITS is 5, the TENS is 8, and the HUNDREDS is 0.
Certainly, you will find that the table for No. 15 is the same as the result of the calculation above.
