5 roll sensor installation – NORAC UC4.5-BC-GN6 User Manual
Page 12
9
5 Roll Sensor Installation
Before installing the roll sensors, determine if the sprayer has a trapeze style, center pivot style
or high pendulum style boom. For installation on a trapeze style boom refer to Section 5.2.
For installation on a center pivot boom refer to Section 5.3. For installation on a high
pendulum boom refer to Section 5.4
Figure 8: Trapeze Style Boom
Figure 9: Center Pivot Boom
Trapeze
Links
Center
Pivot
