8 Hydraulic Installation
Ensure all pressure has been bled from the system before disconnecting any lines
or fittings. Hydraulic pressure will exist on the wing tilt circuits unless the wings
are being supported by other means. The hydraulic installation may be performed
with the wings in transport position, resting on the ground or with the tilt cylinders
fully extended.
Component failure due to oil contamination is not covered under the NORAC
UC4.5 system warranty. It is recommended that a qualified technician perform the
hydraulic installation.
Before assembling the valve block, identify if the sprayer tilt cylinders are single
acting or double acting. A single acting cylinder will only have one hose running to
it, while a double acting cylinder has two hoses routed to it.
NORAC provides proportional hydraulic valves for sprayer boom applications. For
the generic installation kit, the customer must supply all hoses and fittings
required. The fittings (F07) on the NORAC valve block are #6 MB (male ORB) to
#6 MJ (male JIC). The mating female JIC fitting is needed on the hoses. If an
adapter is required, add it after the JIC portion of these fittings. For a typical
hydraulic layout, refer to the installation instructions and the appropriate hydraulic
schematic (Figure 5 or Figure 7).
8.1 Valve Assembly: Single Acting
1. On a clean surface remove the plastic plugs from the block.
2. Install the 6MB-6MJ (F07) fittings into the P and T ports. Tighten to 18 ft-lbs (24 Nm).
3. Insert the two orifices (F08) into the “B” ports with the notch facing out.
4. Install the 6MB-6MJ (F07) fittings into the “B” ports. Tighten to 18 ft-lbs (24 Nm).
5. Install the 6MBP (F09) plugs into the “A” ports. Tighten to 18 ft-lbs (24 Nm).
Fitting F07 is a special fitting; if an additional coupler is required, contact NORAC.
