8.3 Hydraulic Plumbing
From this point on in the installation the booms will be inoperative until the
hydraulics are fully installed.
1. After the NORAC valves are mounted, the hydraulic hoses and fittings can be plumbed. The
plumbing for the hydraulic circuit is shown schematically in Figure 3.
2. Disconnect the tilt cylinder “raise” lines from the sprayer valve block and insert the 6FJXR-
6MJT tees (F04). Reconnect the “raise” lines.
3. Connect straight end of two hoses (H01) to the free end of the tees (F04).
4. Connect the other end of the hoses (H01) to the “B ports” on the NORAC valve block.
5. Disconnect the pressure hose from the sprayer valve block and insert a 6FJXR-6MJT tee
(F04). Use the 8FJXR-8MJT tee (F07) if needed.
6. If the F04 tee was used, connect the straight end of hose H01 to the free end of the tee. If
the F07 tee was used, connect the straight end of hose H02 to the free end of the tee.
7. Connect the other end of the hose to the pressure port on the NORAC valve block.
8. Disconnect the tank hose from the sprayer valve block and insert a 6FJXR-6MJT tee (F04).
Use the 8FJXR-8MJT tee (F07) or the 10FJXR-10MJT tee (F10) if needed.
9. If the F04 tee was used, connect the straight end of hose H01 to the free end of the tee. If
the F07 tee was used, connect the straight end of hose H02 to the free end of the tee. If
the F10 tee was used, connect the 10FJ-6MJ adapter (F11) to the free end of the tee.
Connect the straight end of hose H01 to F11.
10. Connect the other end of the hose to the tank port on the NORAC valve block.
