Muchmore Cell Equalizer (MR-CEK/MR-CEB/MR-CEP) - Manual (Page 2)

CAUTION
PRODUCT WARRANTY
SPECIFICATIONS
HOW TO OPERATE
Cell Equalizer
CONTACT
Muchmore Racing(or their associated distributors) shall not be liable for any
property damage or personal injury which may result from the failure to follow these
instructions or other improper use of this product.
To reduce the risk of injury, use only rechargeable Sub-C size Ni-CD or Ni-MH
batteries with the The Cell Equalizer.
Do not leave the The Cell Equalizer unattended.
Do not charge your cells on the tray.
Be careful with your hands when you tray the battery pack as the nickel bars have
sharp edges.
If cells are too hot to touch there is something wrong and the pack must be
disconnected from the discharger.
Avoid any contact of your Celll equalizer with water or other liquids.
Never operate on carpets, cloths, pit towel or other materials.
Disconnect battery pack from the Cell Equalizer when not in use.
Only discharge serially switched battery packs or cells containing 1~6cells .
New discharger may produce a slight odour in the first few hours of service due to
materials curing inside the device.
1. Tray your battery pack on The Cell Equalizer. Make sure
battery pack's direction is correct. Battery bars are printed on the
tray in white color/colour.
2. If the direction is wrong, LEDs won't turn on.
3. If the direction is correct and the battery pack is charged,
5LEDs will turn on and then off when the discharge is done.
※ UNTRAY YOUR BATTERY PACK FROM THE DISCHARGER IMMEDIATELY
AS SOON AS RED LED IS OFF. UNLESS, PACK EQUALIZER WILL KEEP
DISCHARGE THE PACK AT VERY LOW RATE. IT MAY CAUSE SOME OF
NIMH CELLS TO PERMANENT DAMAGE.
The Cell Equalizer is a new individual auto cut discharger for straight
/saddle pack . This discharger provides Maximum 3A discharge rate and
auto cut off at 0.9V for each cell.
Auto cut off battery individual discharger
138 x 90 x 24mm
129g
Sub C Cell type 1-6cells (1.2-7.2V)
3A
0.9V
Wireless operation
Dimensions.....................................................................
Weight..................................................................................................
Number of cells(Ni-MH/Ni-Cd)..........
Max discharge current...........................................................................
Discharge cuttoff voltage.....................................................................
Input voltage................................................................
2008 MUCHMORE
All products from Muchmore Racing are manufactured according to the highest quality
standards. Muchmore Racing guarantees this product to be free from defects in materials or
workmanship for 120days from the original date of purchase verified by sales receipt. This
limited warranty doesn’t cover defects, which are result of normal wear, misuse or improper
maintenance. This applies among other things to:
■
Mechanical damage of the case
■ Mechanical damage of electronic components/PCB Soldered on the PCB (except on
external solder-tabs)
With Limited Lifetime Warranty products, the warranty terms on the Limited Lifetime
Warranty card do also apply. To eliminate all other possibilities or improper handling, first
check all other components and the trouble shooting guide before you send this product for
repair or warranty. Product sent in for repair, that operate perfect have to be charged with a
service fee. By sending in this product, you assign Muchmore Racing to repair the product,
if it is no warranty or Limited Lifetime Warranty case. The original sales receipt including
date of purchase needs to be included. Otherwise, no warranty can be granted. For quick
repair and return service, add your address and detailed description of the malfunction. Our
limited warranty liability shall be limited to repairing the unit to our original specifications. In
no case shall our liability exceed the original cost of this unit. Because we don’t have control
over the installation or use of this product, we can’t accept any liability for any damages
resulting from using this product. By installing or operating this product, the user accepts all
resulting liability.
The specifications like weight, size and others should be seen as guide values. Due to
ongoing technical improvements, any change for the interest of the product might happen.
Muchmore Racing does not take any responsibility for the accuracy of these specs.
MUCHMORE RACING DISTRIBUTOR SERVICE
Package your product carefully and includes sales receipt and detailed description of
malfunction.
Send parcel to your national Muchmore Racing distributor. Distributor repairs or exchanges
the product.
Shipment back to you usually by COD(cash on delivery), but this is subject to your national
Muchmore Racing distributor’s general policy.
MR-CEK Cell Equalizer Black (1-6cells Individual Auto-cut Discharger)
MR-CEB Cell Equalizer Blue (1-6cells Individual Auto-cut Discharger)
MR-CEP Cell Equalizer Purple (1-6cells Individual Auto-cut Discharger)
