Millennia Media HV-3R page 28 of 40
LAN/MIDI Remote
Local
Remote
Save
Recall
Status
Utility
Ver
MAC
IPAddr
Pwr
AdvP
Test Mode
Timeout
ClearMem
Dflt
Setup
Current IP
192.168.1.201
Power
470C, 3.3 >
Firmware Version
Ver. 0.132.3
MAC Address
001BFF01F080
Restore Default?
No. Yes
Clear Flash?
No. Yes
Menu Timeout
Sec
None, 60, 180
Adv. Parameters
Gain Range
Gain Range
Max 69dB
Test Mode
Switch Test
Test Mode
LED Test
Test Mode
LCD Test
Test Mode
Encoder Test
Test Mode
Watchdog Test
Test Mode
Factory Test
Advanced Menu Mode
To access push both Left and Down buttons at the same time after selecting Advanced Mode.
These controls can get you into trouble, so be careful with function like clearing
memory and resetting defaults. They have no undo.
1) System Status – Displays the status of various
parameters currently active on the unit.
(A) LAN Address – Displays the current IP Address the
unit is using.
(B) Power Supply – Displays the temperature and
various voltages of the power supply.
(i) Temp ###C
(ii) +48
(iii) +24
(iv) +5
(v) +3.3
(C) Firmware Ver ##.## – Displays the current
firmware version running on the unit.
(D) MAC Address – Displays the MAC Address assigned
to the unit.
2) Utilities
(A) Restore defaults – Restores to factory defaults
without affecting user memory. Don’t do this unless
you are instructed by Millennia Service.
(B) Clear User Memory – Clears user memory locations
(C) Menu time out – Sets length of time (seconds)before
returning to the top of the main menu.
(i) None, 60, 180
(D) Advanced Parameters – Allows access to advanced or
extended parameters.
(E) Gain Range – Choice between a maximum gain of
69dB or 80dB. (special button combination to
change: Left Right Down, Down.)
(F) Factory Test Mode
(i) Switch test
(ii) LED test
(iii) Encoder test
(iv) Watch dog
(v) Factory test
