10
SYSTEM EXCLUSIVE
NOTE-ON FILTER
To program the F8 to send out a System Exclusive message when a footswitch is depressed, send it the following
System Exclusive Programming commands:
followed by
where is the System Exclusive message the F8 is being programmed to send
All bytes must be in Hexadecimal format (see hexadecimal conversion table at end)
= Footswitch Input (00 for Fsw1 ... 07 for Fsw8)
To program the F8 to send out a System Exclusive message when a footswitch is released, send it the following
System Exclusive Programming commands:
followed by
where is the System Exclusive message the F8 is being programmed to send
All bytes must be in Hexadecimal format (see hexadecimal conversion table at end)
= Footswitch Input (00 for Fsw1 ... 07 for Fsw8)
To program the F8 to send out the MIDI Machine Control command (F0 7F 7F 06 02 F7) when Fsw4 is
depressed, and the MIDI Machine Control command (F0 7F 7F 06 01 F7) when Fsw4 is released, send the F8
the following System Exclusive Programming commands:
F0 00 00 50 24 06 F7 followed by
F0 00 00 50 24 06 F7 followed by
To program the F8 to filter Note-On messages on a selected MIDI channel when a footswitch is depressed, send it
the following System Exclusive programming command:
= Footswitch Input (00 for Fsw1 ... 07 for Fsw8)
= MIDI channel (see MIDI channel table at end)
= : Send All-Notes-Off on depression of footswitch, do not send All-Notes-Off on depression
To start filtering Note-On messages depress the footswitch (the All-Notes-Off message is sent out at this time), to
stop filtering release the footswitch.
F0 00 00 50 24 06 ii 01 F7 F0 ... F7
F0 ... F7 (max. 20 byes)
ii
F0 00 00 50 24 06 ii 00 F7 F0 ... F7
F0 ... F7 (max. 20 byes)
ii
Example
03 01 F0 7F 7F 06 02 F7
03 00 F0 7F 7F 06 01 F7
F0 00 00 50 24 0C ii cc aa F7
ii
cc
aa 01 aa = 00:
Play
Stop
