Campbell (MAXREFDES4#) Nexys 3 Quick Start Guide
12
be necessary to locate an alternative. Several are available; one good choice is
called Tera Term (http://ttssh2.sourceforge.jp/). Whatever terminal program you
choose, the communication should be set up by opening the COM port number
previously described above and the port configured as:
bits per second: 460,800;
data bits: 8;
parity: none;
stop bits: 1;
flow control: none.
10. Use the Xilinx SDK to download and run the executable ELF (.ELF) file on the
MicroBlaze using the following steps.
Right-click the mouse while the MAXREFDES4 C project is selected, choose the
Run As menu, and then Run Configurations… menu as shown below.
