71M6515H Quick Start Guide
Revision 2.0 2 of 2
© Copyright 2004-2005 TERIDIAN Semiconductor Corporation
Demo Board Test Setup
The file DBUM6515.pdf is a document containing detailed instructions on how to set up and use the Demo Board.
This document should be carefully read and understood before attempting to use the Demo Board.
The figure below shows the basic connections of the Demo Board plus Debug Board with the external equipment.
Power
Power Host PC
Debug
Board
Power Supply
(100 to 240VAC,
1ADC Output)
Demo
Board
Power
Country-Specific Adapters
US
UK
Australia
Europe
GUI
Using the Demo Board
The Demo Board is a ready-to-run meter with a Kh of 3.2 Wh/pulse (if used with CTs with 2,000:1 winding ratio). The
Demo Board has been tested on a meter calibration system, but it has not been calibrated. Please refer to the Demo
Board User’s Manual for further details on how to use the Demo Board.
Documentation
All data sheets and User’s Manuals are provided in electronic form, i.e. on the CD-ROM supplied with this kit. The
TERIDIAN Semiconductor web site should be checked frequently for updates.
Software/Utilities
The PC program (GUI) can be found on the supplied CD-ROM. The Windows ® 2000 operating system is required to
run the executable (PMTest.exe).
Support
Support is available from:
TERIDIAN Semiconductor Corporation
6440 Oak Canyon Rd.
Irvine, CA 92618-5201
Phone: (714) 508-8800 ▪ Fax: (714) 508-8878
http://www.teridian.com/
[email protected]
TERIDIAN Semiconductor Corporation makes no warranty for the use of its products, other than expressly contained in the
Company’s warranty detailed in the TERIDIAN Semiconductor Corporation standard Terms and Conditions. The company
assumes no responsibility for any errors which may appear in this document, reserves the right to change devices or
specifications detailed herein at any time without notice and does not make any commitment to update the information
contained herein.
