71M6521 Quick Start Guide
Revision 1.0 2 of 2
© Copyright 2004-2006 TERIDIAN Semiconductor Corporation
Demo Board Test Setup
The file DBUM6521.pdf is a document containing detailed instructions on how to set up and use the Demo Board.
This document should be carefully read and understood before attempting to use the Demo Board.
The figure below shows the basic connections of the Demo Board plus Debug Board with the external equipment.
Power
Host PC
Debug
Board
Demo
Board
Spacer
removed
Using the Demo Board
The Demo Board is a ready-to-run meter with a Kh of 1.0 Wh/pulse (if used with a CT with a 2,000:1 winding ratio).
The Demo Board has been tested on a meter calibration system, but it has not been calibrated. Please refer to the
Demo Board User’s Manual for further details and on how to configure the Demo Board for shunt configuration.
Documentation
All data sheets, user’s manuals and user’s guides are in electronic form, i.e. on the CD-ROM supplied with this kit.
The TERIDIAN Semiconductor web site should be checked frequently for updates.
Software/Utilities
Demo code, source files, and libraries can be found in electronic form on the supplied CD-ROM. The CD-ROM also
contains all tools and utilities described in the documentation.
Support
Support is available from:
TERIDIAN Semiconductor Corporation
6440 Oak Canyon Rd.
Irvine, CA 92618-5201
Phone: (714) 508-8800 ▪ Fax: (714) 508-8878
http://www.teridian.com/
[email protected]
