Desktop Installation
1. Install the switch on a level surface that
can support the weight of the unit and
the relevant components.
2. Plug the switch with the female end of
the provided power cord and plug the
male end to the power outlet.
Rack-mount Installation
Rack mounting facilitate to an orderly
installation when series of networking
devices circumstance needed. The switch is
supplied with rack mounting brackets and
screws for rack mounting the unit.
Procedures to Rack-Mounting the Switch in
the rack:
1. Disconnect all the cables from the
switch before continuing.
2. Place the unit the right way up on a
hard, flat surface with the front facing
you.
3. Locate a mounting bracket over the
mounting holes on one side of the unit.
4. Insert the screws and fully tighten with
a suitable screwdriver.
5. Repeat the two previous steps for the
other side of the unit.
6. Insert the unit into the rack and secure
with suitable screws.
7. Reconnect all the cables.
