System LED:
LED
Status
Operation
Steady Green
The switch is
powered on
Power
Off The
switch
is
powered off
Port LEDs
LED
Status
Operation
Green
The port is connected
Blinking
Green
Data transmitting
/receiving.
10/100M
Off
No valid link on this
port
Green
One PoE compliant
device is connecting
with this port.
PoE
Off
There is no PoE
compliant device
connecting with this
port.
The Rear Panel
The rear panel consists of one power
receptacle and 8 RJ-45 ports. Port 1 to Port
4 also support connecting to PoE devices.
4
