Positioning of converter – Longshine LCS-883C-TB User Manual
Page 10
10Base-T to 10Base-2 Converter
Positioning of Converter
The following are drawings of typical Applications for the Converter.
Obviously the actual distances will depend on your network, the
quality of cables used, and the terminal equipment employed.
Example 1
The unit allows conversion from 10Base-T UTP to 10Base-2
Coaxial cable. In this configuration, equipment can be added to
existing 10Base-T networks. Distances of up to 185 meters can
be achieved.
