10Base-T to 10Base-2 Converter
Installing Your Converter
10Base-T Connection
1. Make sure that the length for straight through
twisted pair cable between 10Base-T device (hub
or switch) and the Converter is no greater than
100 meters.
2. Connect one end of twisted pair cable to RJ-45
jack on the Converter and the other to the RJ-45
jack on the 10Base-T device.
3. Check the corresponding port LED on the
Converter to be sure that the connection is valid.
(Refer to LED chart in next section)
-10-
