Manual tire winch operation – Lippert Components Bike and Tire Rack User Manual
Page 6

Rev: 09.25.2014
Page 6
Bike Rack and Tire Carrier Owner's Manual
Manual Tire Winch Operation
1. Place the tire directly underneath the spare tire bracket.
2. Thread the winch portion of the of the tire bracket assembly through the wheel hub opening (Fig. 18).
3. Adjust the winch until it sits flush with the inside of the tire rim (Fig. 19).
A
Fig. 20
4. By using the manual crank (Fig. 20A) or with a hand wrench, lower (counter-clockwise) or raise
(clockwise) the tire. While raising the tire, take great care to assure that the winch is still in position.
Fig. 19
Fig. 18
