Schwintek in-wall™ troubleshooting guide – Lippert Components Schwintek In Wall Slide-Out System User Manual
Page 4
Rev: 01.30.2015
Page 4
Lippert In-Wall Troubleshooting Guide
Motors and Harnesses
1. Check for proper connections between the motors and harnesses.
2. Visually inspect the exposed harnesses to ensure they are not pinched or damaged.
3. If test harness is available, connect the test harness from the controller to the motor and try to operate
the slide-out using the normal switch.
4. If test harness is not available, ohm test the harness.
Fig. 2 - Motor and Harness
SCHWINTEK IN-WALL™ TROUBLESHOOTING GUIDE
