Lippert Components Ultra Level - Manual (Page 11)

WIRING DIAGRAM
RED - IGNITION
WHITE - P
ARK BRAKE;
GROUND
BLACK -
AIRBAG DUMP
YELLOW
- AIRBAG
FILL
1 2 3
4 5 6
7 8 9
ICICL
4-PIN PHONE HARNESS
12-PIN WIRE HARNESS 1 – WHITE(CHASSIS POWER) 2 – BLACK W/WHITE(PUMP RETRACT 3 – RED(CURBSIDE REAR V
A
L
VE)
4 – GREEN (ROADSIDE FRONT
V
A
L
VE)
5 –
YELLOW (PSI SWITCH)
6 – BLUE (ROADSIDE REAR V
A
L
VE)
7 – BROWN (GROUND) 8 – PURPLE (CURBSIDE FRONT
V
A
L
VE)
9 – GREY (PUMP EXTEND) 10 -
A
U
X
1
1
-
AUX
12 -
A
U
X
15A FUSE
PLUGS INT
O PUMP
HARNESS
PROVIDED BY LCI
Fig. 9
DIRECTIONAL
V
A
L
V
E
