E. adjusting diopter, F. installing battery, G. adjusting reticle illumination – Leapers 30mm 36-color Crossbow Scope (SCP3-1428CRWQ) User Manual
Page 8: H. adjusting magnification

15
16
e. adjusting diopter
(Eye Piece Adjustment)
Diopter adjustment provides additional focus adjustment to adapt the
scope to your eyesight.
1. Diopter adjustment ring is located at
the ocular end of the scope. Point
the scope at an uncluttered and light
colored background object, such as a
white wall. Look through the scope and
turn the dial ring clockwise or counter-
clockwise until the reticle looks the
sharpest to you at the first glance.
2. Note:
Different individuals will have different eye focus which will
result in different diopter setting. A person will use different diopter
settings with or without eye glasses.
1. The battery is housed inside the EZ-TAP Battery housing or the side
wheel red/green illumination rheostat.
2. Firmly hold the housing or the rheostat with 2 fingers.
3. Use your other hand to unscrew the top cap of the battery
compartment.
4. Verify the battery included with your scope. It is either CR2032,
CR1632 OR CR1620. Remove the old battery(if there is one) and
install a new one of the same type. Make sure the positive (+) side is
facing up or out.
5. Replace the cap and screw it clockwise to tighten.
F-1. EZ-TAP
F-2. Side Rheostat
F. installing battery
(For Reticle Intensified Models Only)
g. adjusting Reticle Illumination
(For Reticle Intensified Models Only)
Operating in
M
u
l
t
i
-
C
o
l
o
r Mode for
IE
Models
1. Press the
R
button to change the color along
the color axis in the Color Index Table.
2. Press the
G
button to change the color along
the intensity axis in the Color Index Table.
Operating in the
R
G
B Mode
1. Press the
R
button to turn the red light on or
to change brightness of the red light.
2. Press the
G
button to turn the green light on
or to change brightness of the green light.
Turn On/Off
1. Press either the
G
or
R
button to turn on
the light.
2. Press and hold either the
G
or
R
button
for 1 second to turn off the light.
3. Light will go off after 1 hour with no action.
G
R
G
OR
R
G
R
G
OR
R
G
R
G
OR
R
Color Index Table
Magenta Thistle
Plum
Violet
Orchid
Purple
Pink
Rosy
Brown
Coral
Crimson
Brown
Maroon
Yellow
Khaki
Orange
Golden
Rod
Chocolate
Olive
Law
Ngreen
Plae
green
Spring
Green
Olive
Drab
Sea
Green
Forest
Green
Cyan
Azure Turquoise Cadet
Blue
Dark
Cyan
Teal
Blue
Skyblue Dodger
Blue
Indigo
Midnight
Blue
Navy
Color
Intensity
G Button
R Butt
on
36
fUll
i
e
colors
G-1.
Standard Rheostat
G-2.
Compact Rheostat
G-3.
EZ-TAP
®
Console
G-1 and G-2 Illumination Adjustment
Dial the Rheostat to turn on the illumination and verify its color and
brightness at each position.
G-3 Illumination Adjustment (IE
®
Models)
Memory Feature
When turned on, G-3 illuminated reticle shows the same color and
brightness you last used.
Switching between
R
G
B and
M
u
l
t
i
-
C
o
l
o
r
Modes for
IE
Models
1. Press BOTH
G
&
R
buttons at the same time
for less than 1 second.
G
R
G
AND
R
1. For variable power scopes, there
is a power ring in front of the
eyepiece assembly. To change
magnification, turn the ring to align
the desired number on the ring with
the index dot on the main tube.
2. The lower power provides wider
field of view for quick aiming at
close range. The higher power
is for precise long-range aiming.
When the numbers on the ring
are not visible under low light
condition, turn the ring left to
increase the power, turn the ring
right to decrease the power.
3. Note:
Never loosen the screw
in the power ring. Doing so will
break the sealed state of the scope
and destroy the fogproof feature.
The power ring should not be
disassembled.Do not try to lubricate it.
Any such action will void the warranty.
H-1. Adjusting Power Ring
H. Adjusting Magnification
(For Variable Power Models Only)
H-2. Power Ring Screw
