Lake Lite LL-SML-X User Manual
Solar marine lite, Model: ll-sml-x

Solar Marine Lite
MODEL: LL-SML-X
LIGHT CHARACTERISTICS
Light Source
6-Ultra-High intensity LEDs.
Available LED Colors
White, Blue, Green, Amber, Red
Light Mode Options (user switchable)
Constant & 1/sec. Flashing
Visible Range Constant Light Mode
0.5 – 0.75 nm (Run Time 30hrs Max)
Visible Range Flashing 1/sec Mode
1.0 – 1.25 nm (Run Time 40-45hrs Max)
Horizontal Output (degrees)
360
Vertical Divergence (degrees)
7-10
Intensity Adjustment
Automatic for Constant & Flashing 1/sec.
LED Life Expectancy (hours)
> 100,000 hrs
ELECTRICAL CHARACTERISTICS
Circuit Protection
Integrated
Nominal Voltage (v)
1.2v
Autonomy (hours) Constant Mode
30hrs
Autonomy (hours) Flashing 1/sec Mode
40-45hrs
Temperature Range
-30 to 80 C
SOLAR CHARACTERISTICS
Solar Module Type
Multicrystalline
Power (watts)
0.45 watts
Solar Module Efficiency (%)
14-16%
POWER SUPPLY
Battery Type
High Grade NiMh – ECO Friendly
Battery Capacity (mAh)
2500 mAhr
Nominal Voltage (v)
1.2v
Battery Service Life
3-4 years (Varies with local Environment)
Battery Service Access
Yes: User Changeable / Replaceable
PHYSICAL CHARACTERISTICS
Body Material
UV Stabilized Poly Carbonate
Lens Material
UV Stabilized Poly Carbonate
External Lens Design
Fresnel Lens
Internal Lens design
360 Deg. Lenticular
Water Proof Rating
IP 68
Mounting
4 x 5mm mounting holes
Height
110.8mm
Width / Diameter
130.94mm
Weight
1kg
OPTIONS
Custom Mounting & Hardware
Please Contact
Custom Flash Patterns and IALA Codes
Please Contact
* Information subject to change without notice
Solar Marine Dock Lite: Model LL-SML-X
The Solar Marine Lite is an industrial strength solar
powered light designed for harsh environments. Available
in five colors and changes easily between constant &
flashing mode. High intensity LED’s and powerful solar
panel provide all night illumination. Perfect for dock
lighting, marinas, boat houses, safety lighting, channel
markers, buoys, obstruction lighting, mooring lights, or
anywhere a light may be needed. Mounts virtually
anywhere in minutes providing a fast & cost effective
lighting solution.
Lake Lite Inc.
2301 Fairfield Ave, Suite 107
Fort Wayne, IN 46807
Phone: 260-918-2758
Fax: 260-918-3540
E-mail [email protected]
www.lakelite.com
www.solarmarinelites.com
