LAARS Heating Systems

Page 36

GAS TRAIN COMPONENTS

See Figure 23

80

Weldment, Gas Manifold, Main

L0063702

L0063703

L0063704

81

Manifold, Gas, On/Off

L0063414

L0063416

L0063418

82

Manifold, Gas, 2 Stage Left Bank

L0063404

L0063413

L0063414

83

Manifold, Gas, 2 Stage Right Bank

L0063402

L0063403

L0063405

84

Orifice, Nat. Gas

L0062900

L0062900

L0062900

Orifice, LP Gas

L0063000

L0063000

L0063000

85

Spacer, Gas Orifice

F2022400

F2022400

F2022400

86

Gas Valve, Combination, Nat. (DSI) 3/4" NPT x

3/4" NPT

V0079400

V0079400

V0079400

Gas Valve, Combination, LP (DSI) 3/4" NPT x

3/4" NPT

V0079500

V0079500

V0079500

87

Cover, Gas Inlet, Air Box

2C2018

2C2018

2C2018

Item

Description

Model 200

Model 300

Model 400

CONTROL PANEL COMPONENTS

See Figure 24

92

Bracket, Mounting, Hi-Limt/Pressure Switch

2C7004

2C7004

2C7004

93

Switch, Pressure, Diaphragm, SPST

E0255500

E0255500

E0255500

94

Switch, Pressure, Diaphragm, SPDT

RE0240900

RE0240900

RE0240900

95

Switch, Limit, High Temperature, Hydronic

E2304800

E2304800

E2304800

Switch, Limit, High Temperature, Volume Water

E2324200

E2324200

E2324200

96

Transformer, 24, 120 V, 50VAC

E0180500

E0180500

E0180500

97

PCB, TCM

MT2H

MT2V

RE2344300

RE2344301

RE2344301

RE2344301

RE2344301

RE2344301

98

Switch, Toggle, SPDT

R2007700

R2007700

R2007700

99

Tray, Control Panel

2F7001

3F7001

4F7001

101

Relay, 24VAC, DPDT

E2327800

E2327800

E2327800

102

Ignition Control

E0253400

E0253400

E0253400

103

Switch, Rocker, 15A, 125 VAC, 1/2 HP

RE2322700

RE2322700

RE2322700

104

Terminal Block

E2327700

E2327700

E2327700

105

Cover, Transformer

2C7005

2C7005

2C7005

106

Label, Terminal Block

H2356600

H2356600

H2356600

108

Stablilzer, Control Panel

2C7006

2C7006

2C7006

not shown

Harness, Main

E2348700

E2348700

E2348700

Item

Description

Model 200

Model 300

Model 400
