5 overview, model 2000 – LAARS MagnaTherm MGV - Installation, Operation and Maintenance Instructions User Manual
Page 7
MagnaTherm Boilers and Water Heaters
Page 3
Model 2000
Manual
gas valve
Blower
Touch Screen
Heat Exchanger
Condensing Unit
Air Intake and
Filter
Water Outlet
Water Inlet
Vent
Power Pack
Perspective from opposite corner.
Perspective from front left corner.
Shown with front doors and left side
panels removed
Condensate
Trap
1.5
Unit Overviews
The next 3 pages give a visual reference to
the basic component locations of the LAARS
MagnaTherm.
