Stick Wired Remote Control
• Dual-voice Coil
• 120 W High Power Amplifier
with Low Pass Filter
• MaxxBass Circuit for Virtual Bass Enhancer
• 6-3/4″ Counter Drive Woofer
with Dual-neodymium Magnet
• Air Compression Structure with Aluminum
Die-cast Enclosure
• Remote Control For Gain Control /
Low-pass Filter (Selectable 50/75/100/
120 Hz)/phase Select
• Blue LED Power Indicator
• RCA Line Level Input/speaker Level Input
*“Maxx Bass” is a patent of KS-Waves.“MaxxBass”
is a registered trademark of KS-Waves.
SW1251
700W MAX.
12″ Single 4-ohm Voice Coil
Subwoofer
• Speaker type: 6-3/4″ counter drive
powered subwoofer
• Unit used: 6-3/4″ MIPP cone woofer
(Dual Voice coil)
• Rated output: 60W (30W+30W)
• Max power output:120W (60W+60W)
• Playback frequency range: 30 to 200Hz
• Cut-off frequency: 50Hz/75Hz/100Hz/120Hz
• Input sensitivity: RCA input 20mV to 2V,
Speaker input 0.2V to 20V
• Power source voltage: DC14.4V
• Ground: Negative
• Current consumption: 7.0A
• External dimensions:
[Main unit] 12-1/4″ (W) x 2-5/8″ (H) x 8-1/4″ (D)
[Remote control Unit]
3-15/16″ (W) x 1-1/8″ (H) x 1″ (D)
• Weight: [Body] 2.0Kg [Remote control] 220g
SRV314
120W MAX.
Slim Design 6-3/4″ Powered Subwoofer
FEATURES &
SPECIFICATIONS
SW125
1
SW1
0
51
Maximum Music Power (Watts) 700 600
Continuous Power Handling (Watts) 350 300
Single 4 Ohm Heat Resistant
Voice Coil ● ●
Polypro-pylene Electronic Spun
Aluminum Dust Cap
● ●
Fiber Glass / Paper Cone Design ● ●
Nitrile Butadiene Rubber
High Excursion Surround ● ●
Dual Strontium Ferrite Magnets ● ●
Hyper Extended Vented Pole Piece ● ●
S.E.T.(Spider Exhaust Technology)
Cooling ● ●
Dual Gold Plated Terminal Blocks ● ●
Linear Cotton Spider with
Integrated Tinsel leads
● ●
Custom Stamped Steel Powder
Coated Chassis ● ●
Frequency Response (Hz) 30-1k 32-1k
Efficiency (dB/W/m) 90 88
Basket Type Stamped
Steel
Stamped
Steel
Number of Voice Coils 1 1
Impedance (Ohm) 4 4
Outside Dimension (Inch) 12-1/4 10-3/8
Cut Out Size (Inch) 11-5/16 9-5/16
Mounting Depth (Inch) 6-1/2 5-13/16
Enclosure Size (ft 3 ) 0.9 0.5
Performance and Value Exceeding Expectations.
Clarion’s SW Series Subwoofers
Deliver Big Bass Presence with
A Relatively Small Investment.
SW1051
600W MAX.
10″ Single 4-ohm Voice Coil
Subwoofer
CEA-2031 Speaker Rating
Maximum RMS Power: 300 watts
Impedance: 4 ohms
Fiber Glass/Paper Cone Design
Dual Strontium Ferrite Magnets
Spider Exhaust Technology Cooling
Nitrile Butadiene Rubber High Excursion Surround
PLATINUM Series
Separate woofers and tweeters that
let you choose the exact solution
for your car audio upgrading needs.
GOOD Series
The easiest way to pursue better sound
and upgrade from the standard factory
system in your car.
ULTRA Series
Harnessing the highest grade materials
for high power handling, superior
response, and stately looks.
QUALITY Series
Multiaxial speakers combining design
and performance to faithfully reproduce
the full spectrum of sound.
Sound to please the ear and design to catch the eye.
Clarion’s full line of speakers will let you customize your car’s
soundscape with the exact specs and looks you need.
The Sounds and Sensations of Pure Excellence
CEA 2006 Power Ratings
28W × 2RMS [2Ω@14.4Vst%THD+N]
S/N 65dB (Ref.1Winto4Ω)
CEA-2031 Speaker Rating
Maximum RMS Power: 350 watts
Impedance: 4 ohms
