Clarion XW-1200 - Manual

Model: XW-1200
Maximum Power Handling (Coils in Series) ...1000W
Continuous Power (Coils in Series) ...............500W
SPL (Coils in Series) .....................................89dB@ 1W/1M
Frequency Response .................................. 20HZ~1.8KHZ
Woofer Cone Material ................................Polypropylene
Woofer Magnet ..........................................Ferrite
Woofer Basket ..........................................Alumina
Woofer Surround ......................................Rubber
Sealed/Acoustic Suspension
Thiele Small Parameters
Vented/Bass Reflex
OPTIMUM
Enclosure Airspace (Unfilled) = 1.38 ft
3
Enclosure Airspace (Filled) =1.10 ft
3
Fc =51.3 HZ
MAXIMUM FLAT
Enclosure Airspace = 2.64 ft
3
Fb =38 HZ
F3 =37 HZ
Port Size = 3" I.D. x3.76" Length
• Polypropylene Cone W/Titanium Deposition coating
• Rubber Surround
• Dual 4 Ohm Heat Resistant Voice Coil
• Rear Vented Pole Piece
• Large Strontium Ferrite Magnet
• Rubber Magnet Cover
• For Small Sealed or Small Vented Design
Outside Dia 12"
Mounting Hole 294mm
Mounting Depth 168mm
Sensitivity 89 dB
Max. Peak Music 500W*2
Continuous Power 250W*2
Nominal Impedance 1.9 Ohm (paralleled)
Re DC Imp (± 10%) 3.7 Ohm
Le 1.15 mh@1khz
V.C. Diameter 2"
V.C. Length 30mm
Air Gap 8mm
Piston Diameter 260mm
Sd 0. 0531 sqm
Vas 68.119 L (paralleled)
Fs 38.025 HZ(paralleled)
Qts 0.4058 (paralleled)
Qes 0.433 (paralleled)
Mms 114.934 g (paralleled)
Mmd 107.29 g (paralleled)
Rms 3.968 kgs-1(paralleled)
BI 10.98 TM (paralleled)
Speaker Displacement 58.4 CM
3
(paralleled)
Xmax 11mm
Magnet Weight 85.5 oz
Clarion Sales Corporation 661 W. Redondo Beach Blvd., Gardena, CA 90247
Phone: 1-800-GO-CLARION FAX: (310) 327-1999
