1. Technical data
KERN CH 15K20 CH 50K50 CH 50K100
Readability (d) 20 g 50 g 100 g
Weighing range (max) 15 kg 50 kg 50 kg
Taring range (subtractive) 15 kg 50 kg 50 kg
Reproducibility 20 g 50 g 100 g
Linearity ± 40 g ± 100 g ± 200 g
Recommended adjustment
weight, not added (class)
10 kg (M3) 20 kg (M3) 20 kg (M3)
Stabilization time 2 s
Warm-up time 10 min
Units kg, lb, N
Auto off 3 min
Allowable ambient
temperature
5…+ 35 °C
Ambient humidity (max) 80 %
Battery
(in series) 1 x 9 V Block
Operating time 20 h
Display Digit height 11 mm
Housing size W x D x H 90 mm x 30 mm x 176.5 mm
Housing material Synthetic material
Material Hook Stainlees steel
Net weight 250 g
