18 KFD V40-IA-e-1211
11 Preload, Deadload and Overload settings
Kern model max. Preload* (kg)
* = additive preload
Deadload** (kg)
**= already applied
preload
Center Overload
Protection circa (kg) Corner Overload
Protection circa (kg) Loadcell
Capacity (kg)
KFD 600V40M 0 100kg 0 0 500 kg
KFD 600V40LM 0 160kg 0 0 500 kg
KFD 1500V40M 0 100kg 0 0 1000 kg
KFD 1500V40LM 0 160kg 0 0 1000 kg
Platform type Platform dimension
(mm) Loadcell TC Class Max E
max
E
min
Y n Dead-load T
min
T
max
Cable-
Type Nr. Preload -1 -4 -3 (kg)
-5 -6
length
(kg) (kg) (g) (m)
KFD 600V40M 1000x1000 H8C D09-03.19R2 C3 0 500kg 30 15000 3000 100kg -10 40 5
KFD 600V40LM 1200x1200 H8C D09-03.19R2 C3 0 500kg 30 15000 3000 160kg -10 40 5
KFD 1500V40M 1000x1000 SQB TC6911 C3 0 1000kg 100 10000 3000 100kg -10 40 5
KFD 1500V40LM 1200x1200 SQB TC6911 C3 0 1000kg 100 10000 3000 160kg -10 40 5
