8 OEX-BA-e-1410
5 Installation instruction of scale

For OEX scales prepare an appropriate place for installation.

It should be dry, even and rigid

Acceptable operation temperature range -10°C to +40°C

The ground on which the platform is to be placed must be able to carry the
maximal load together with the platform

Scales series OEX without pole featuring an indicator installed on a cable,
enable installing the indicator on a table or fitting it to a wall using a holder.

The indicator can be mounted on the table or installed on a wall by means of a
handler.
o Scale should be unpacked outside the hazardous area.
o After unpacking remove all transport protections:
o Turn the pole and fix it to the platform. Place the surplus cable inside
the pole .
o Lift the weighing pan and remove transport protections.
Load cell conductor
Transport grip
Pole
Washer
Nut
