[Sleep Mode]
Important!
• Storing the watch for long periods in an area where there is no light or wearing it in
such a way that it is blocked from exposure to light can cause storage battery pow-
er to run down. Be sure that the watch is normally exposed to light whenever possi-
ble.
• This watch employs a solar cell that converts light into electricity that charges a
built-in storage battery. Normally, the storage battery should not need replacement,
but after very long use over a number of years, the storage battery may lose its
ability to achieve a full charge. Should you notice problems with getting the storage
battery to a full charge, contact your dealer or CASIO distributor about having the
storage battery replaced.
• The storage battery should be replaced with a CASIO-specified, ML-2020 battery
only. Other storage batteries can cause damage to the watch.
• Be sure to put the watch into its Sleep Mode and keep in an area normally exposed
to light when storing it for long periods. This helps to keep the storage battery from
going dead.
Battery Power Indicator
The battery power indicator on the display shows you the current status of the stor-
age battery's power.
• At Level 4, the display is disabled but timekeeping and other functions continue to
operate internally. Pressing any button causes the Timekeeping Mode screen to
appear for two or three minutes.
• At Level 5, all functions are disabled. Functions are enabled once again after the
storage battery is charged, but anything previously stored in memory is lost. Be-
cause of this, you must set the current time and alarms, and re-input point data
after the storage battery is charged.
• Leaving the watch under strong direct sunlight to charge can cause the battery
indicator to show a battery capacity reading that is higher than the actual level.
Check the level after leaving the watch in an area out of the sun for a few minutes.
Charging Precautions
Certain charging conditions can cause the watch to become very hot. Avoid leaving
the watch in the areas described below whenever charging its storage battery.
Warning!
Leaving the watch in sunlight to charge its storage battery can cause it to be-
come quite hot. Take care when handling the watch to avoid burn injury.
Avoid charging the battery in the high temperature conditions described be-
low.
• On the dashboard of a car parked in direct sunlight.
• Too close to an incandescent lamp.
• Under direct sunlight or in any other area exposed to intense heat for long periods.
Charging Guide
Required charge time when the backlight is used for two seconds and the alarm
sounds for 20 seconds per day:
• Approximately 8 hours of 500 lux (indoor fluorescent lighting) per day
• Approximately 1 hour 20 minutes of 3,000 lux (direct fluorescent lighting) per day
• Approximately 50 minutes of 36,000 lux (afternoon outdoor sunlight) per week (7
minutes per day)
Required charge time when the backlight is used for 30 seconds and the alarm sounds
for 20 seconds per day:
• Approximately 4 hours of 3,000 lux (direct fluorescent lighting) per day
• Approximately 2 hours 20 minutes of 36,000 lux (afternoon outdoor sunlight) per
week (20 minutes per day)
Using the Sleep Mode
In any mode (except while figures are flashing on the dis-
play for input), hold down
C
C
C
C
C
for about two seconds.
• This enters the Sleep Mode, which clears the display.
Time keeping and other functions continue to be per-
formed internally.
• Alarms, the Hourly Time Signal, and the backlight are
disabled while the watch is in the Sleep Mode.
• Pressing any button (except
A
A
A
A
A
) exits the Sleep Mode
and enters the Timekeeping Mode.
About Auto Display
Auto Display is a demonstration feature that continually changes the contents of the
digital display. Note that you cannot use any of the watch's other functions while Auto
Display is operating.
To turn off Auto Display
Hold down
A
A
A
A
A
for about two seconds until the watch beeps.
To turn on Auto Display
1. In any mode (except while figures are flashing on the display for input), hold down
C
C
C
C
C
for about two seconds to enter the Sleep Mode.
2. Hold down
A
A
A
A
A
for about two seconds until the watch beeps. This indicates that Auto
Display is on.
• You cannot turn on Auto Display while a setting screen (indicated by flashing digits)
is on the display.
• Leaving the watch in a dark area can cause Auto Display operation to stop. Normal
operation should resume when the watch is again exposed to light.
• Auto Display cannot be turned on while the storage battery is at Level 4 or Level 5.
Auto Display also turns off automatically whenever the storage battery drops to
Level 4 or Level 5.
Point name
Longitude
Latitude
OGASAWARA
142
°
E
27
°
N
9
6:30
MORETON
153
°
E
27
°
S
10
10:00
MAUI
157
°
W
21
°
N
–10
4:00
VANCOUVER
126
°
W
50
°
N
–8
1:00
BAJA CA
110
°
W
24
°
N
–7
8:50
BAHAMAS
79
°
W
27
°
N
–5
7:40
CANARY IS
17
°
W
28
°
N
0
0:00
CORSICA
9
°
E
43
°
N
1
9:00
ZANZIBAR
39
°
E
6
°
S
3
3:30
BALI
115
°
E
9
°
S
8
10:50
GMT
differential
Lunar Tide
Interval
PRESET LOCATION CHART
OGASAWARA
CORSICA
■
MAUI
BAHAMAS
■
MORETON
VANCOUVER
CANARY IS
■
■
■
■
■
ZANZIBAR
■
■
■
BAJA CA
BALI
OGASAWARA Area around Chichijima Island, which is one of the Ogasawara Is-
lands located about 1,000 kilometers south of Tokyo.
MORETON
Area around Moreton Island, located just off Brisbane, Australia.
MAUI
Area around Maui, located northwest of Hawaii Island.
VANCOUVER Area around Johnstone Strait, Vancouver, Canada.
BAJA CA
Area around the central part of the Baja Peninsula, located south
of California in Mexico.
BAHAMAS
Area around the Little Bahama Bank, located north of the Grand
Bahama Island.
CANARY IS
Area around Gomera Island, which is part of the Canary Islands
(Spain).
CORSICA
Ligurian Sea, located north of Corsica (France).
ZANZIBAR
Area off of Zanzibar, Tanzania.
BALI
Area around Bali, Indonesia.
Level
Indicator
Functional Status
1
All functions enabled.
2
All functions enabled.
3
Alarms, Hourly Time Signal, backlight disabled.
4
5
Alarms, Hourly Time Signal, backlight, display
disabled; timekeeping enabled.
Alarms, Hourly Time Signal, backlight, display,
timekeeping disabled.
