Vermont Casting 1920 - Manual (Page 28)

28
Aspen Woodburning Stove
30000369
Aspen Woodburning Stove
Model 1920 (continued)
1. Top See Chart Pg. 28
2. Right Side See Chart Pg. 28
3. Secondary Air Channel, Right 30000606
4. Left Side See Chart Pg. 28
5. Secondary Air Channel, Left 30000607
6. Secondary Air Tube 30000368
7. Bottom 30000343
8. Bottom, Inner 30000346
9. Ashlip See Chart Pg. 28
10. Ashpan 30000363
11. Thermostat Cover 30000371
12. Back 30000347
13. Fireback 30000358
14. Leg (4) See Chart Pg. 28
15. Leg Bolt, 3/8”-16x1” hex bolt (4) 1201432
16. 3/8” Flat Washer (4) 1202488
17. Primary Air Plate 30000356
18. Grate, Wood 30000604
19. Firebrick (10) 1601103
20. Flue Cover See Chart Pg. 28
21. 5/16” Adhesive Gasket 1203591
22. Front See Chart Pg. 28
23. Door See Chart Pg. 28
24. Primary Air Flap 30000370
25. Door Handle Catch 30000365
26. Wooden Handle 30000366
27. Door Handle Shaft 30000364
28. Door Pin, Long 1600416
Item Description Part Number
29. Glass Gasket, horizontal (8¹⁄₄") 30000382
30. Glass Gasket, vertical (2) 30000383
31. Glass Panel 30000362
32. Glass Retainer (2) 30000474
33. Glass Clips (2) 1601394.
34. Door Manifold 30000357
35. Flue Collar See Chart Pg. 28
36. Friction Spring 1201846
37. Primary Thermostat Assembly 30000503
38. 1/4" Flat Washer, Zinc (10) 1202474
39. 1/4-20x5/8" Hex Screw (2) 1201372
40. 1/4-20x1¹⁄₄" Flt Hd Phillips Screw 1200811
41. 1/4-20x3/4" Flat Hd Phillip Screw (6) 1200881
42. Ball Chain, Thermostat 1201960
43. 10-20x1/4" Plain Truss Head Screw (5) 1200996
44. 1/4-20x5/8" Round Hd Phillips Screw (2) 1200896
45. 1/4-20x3/8" Round Hd Philips Screw (2) 1200894
46. 1/4 Flat Washer (4)
1202475
47. 7/16” Round Gasket (9.3ft.) 7000910
48. 10-24x3/8" Round Hd Slotted Screw (6) 1200983
49. 3/16"x1" Roll Pin
1201833
50. 1/4-20x1" Hex Head Screw (8) 1201326
51. Gasket, Flat w/adhesive (3 ft.) 30000504
52. 1/4-20x3/8" Pan Hd Phillips Screw 1201053
53. Deflector Rib 30000597
54. Bottom Heat Shield 0001895
55. Handle,Screw Pan head Phillips 1200986
56. Washer, Flat #10 .218 id x .5 od 1202423
Item Description Part Number
Shell Enamel Parts - Aspen
Forest Suede Vermont
Part Name Classic Ebony Green Brown Classic Green Bordeaux
Top III 30001654 30001660 30001661 30002588 30003167 30004007
Left Side II 30001656 30001664 30001665 30002591 30003170 30004010
Right Side II 30001655 30001662 30001663 30002590 30003169 30004009
Flue Collar 30000353 30000483 30000492 30002589 30003168 30004008
Flue Cover 30000351 30000481 30000490 30002585 30003164 30004004
Front 30000348 30000478 30000487 30002586 30003165 30004005
Ashlip 30000352 30000482 30000491 30002593 30003172 30004012
Door 30000350 30000480 30000489 30002587 30003166 30004006
Leg Set
of Four 30000502 30000539 30000540 30002594 30003173 30004013
Single Leg 30000360 30000484 30000493 30002592 30003171 30004011
