Page 20
18
Antenna Positioning with Business Grade Modem
WiFi
Modem
When connecting the provided antennas,
review the connection points.
WiFi antennas have flat circular bases.
Modem antennas have protruding pins.
CradlePoint recommends the following antenna positioning for best performance.
Verizon: MBR1400LE-VZ (LTE/EVDO), MBR1400E-VZ (EVDO)
Sprint: MBR1400W-SP (WiMAX), MBR1400E-SP (EVDO)
Desk Mount Use
(All modems desk mount)
Note: Desk mount not recommended for Sprint WiMAX
Wall Mount Use
(All modems wall mount)
