Cradlepoint CTR350 - Manual

CTR350
3G Mobile
Broadband
Travel
Router
QUICK START GUIDE
Establishing a Wireless Internet Connection
Wireless Setup using a Mobile Broadband
(cellular) Data Modem * or Compatible Phone
Connect Power Supply and insert a USB modem or compatible Phone via USB.
Then establish a wireless internet connection as shown below.
Wired Connection using Cable/DSL Internet Service
Note: CradlePoint recommends that WiFi security be setup at this point.
See the “ Setting WiFi security on your CradlePoint Router” section of this guide.
RegisterÊ yourÊ CTR350Ê
MobileÊ BroadbandÊ RouterÊ Today!
cradlepoint.com/register
or Power
Supply
* Mobile Broadband Data Modem not included.
See your Mobile Broadband Service Provider for details.
Modem
Internet
Service (ISP)
What’s Included In The Box
Port Diagram
FREE Technical Support New Product Information
Special Offers & Promotions
FREE Firmware Upgrades
~ YOU WILL RECEIVE ~
• 3G Mobile Broadband Travel Router • Quick Start Guide • AC Power Adapter
Windows XP
Open your computer’s WIRELESS NETWORK
CONNECTION to associate with the router’s Wireless
Access Point. This is typically completed by opening
VIEW AVAILABLE NETWORKS window. After you
have highlighted the CTR-xxx, click CONNECT.
1) Find Your CTR350
Ethernet
Cable
USB Modem
Phone
via
USB
Power
Supply
LEFT SIDE
LEDs
USB
POWER
RIGHT SIDE
RESET
AIR VENTS
WAN
CTR350
CTR350
CTR350
Windows Vista
Open CONNECT TO A NETWORK by clicking
the Start button, and then click CONNECT TO.
You'll see a list of the wireless networks
currently available. Click on the CTR-xxx
network, and then click CONNECT.
1) Using either a Windows or Mac platform, open a browser window.
A default CradlePoint page will appear asking for a password.
2) The password is the last six digits of the MAC address shown on the box label
and on the bottom of the router. This is a unique number identifying your router.
3) Once you have correctly entered your password, click “OK”.
You can now access the Internet.
Mac
Open your wireless connection list by
clicking the AIRPORT wireless icon
on your menu bar. Click the CTR-xxx.
2) Connect To the Internet
Note: CradlePoint recommends
that WiFi security be setup at
this point. See the “ Setting WiFi
Security on your CradlePoint
Router” section of this guide
Also, get a FREE Car Charger!
Connect power and insert one end of your Ethernet cable (not included) to the WAN port. Insert the
other end of the Ethernet cable into your Internet service provider's modem. It may take a minute or
two for the CTR350 to initialize. Open your web browser.
You can now access the Internet.
POWER
WLAN
WAN
USB
