QUICK START GUIDE

Establishing a Wireless Internet Connection

Wireless Setup using a Mobile Broadband

(cellular) Data Modem or Compatible Phone

Connect Power Supply and USB modem.*
Then establish a wireless internet connection as shown below.

RegisterÊ yourÊ PHS300Ê

PersonalÊ WiFiÊ HotspotÊ Today!

FREE Technical Support

Special Offers & Promotions

cradlepoint.com/register

* Mobile Broadband Modem not included. See your Mobile Broadband Service Provider for details.

What’s Included In The Box

3G/4G Personal WiFi Hotspot

Quick Start Guide

New Product Information

FREE Firmware Upgrades

~ YOU WILL RECEIVE ~

Li-Ion Battery

AC Power Adapter

Windows XP

Open your computer’s “Wireless Network

Connection” to

associate with the router’s

“Wireless Access Point.” This is typically

completed by opening the “View Available

Wireless Networks” window. After you

have highlighted the PHS-xxx, click the

“Connect” button.

Windows Vista

Open Connect to a Network by clicking the

Start button, and then clicking Connect. In

the “Show” list, click “Wireless”. You'll see

a list of the wireless networks currently

available. Click on the PHS-xxx network,

and then click Connect.

Mac

Open your Mac’s wireless connection list

by clicking the “Airport” icon on your menu

bar. Highlight the PHS-xxx.

1) Using either a Windows or Mac platform, open a
browser window. A default CradlePoint page will
appear asking for a password.

2) The

password is the last six digits of the MAC

address shown on the box label and on the
bottom of the router. This is a unique number
identifying your router.

3) Once you have correctly entered your password,
click “OK”.

You can now access the Internet.

Note: CradlePoint recommends that WiFi security

be setup at this point. See the “

Setting WiFi security

on your CradlePoint Router” section of this guide.

I

dentify the PHS300

find connection starting with “PHS”

PHS300

3G/4G

Personal

WiFi

Hotspot

USB

Power

Supply

Battery

Connect mobile

broadband modems

Share Your Internet Connection With Up To

16 WiFi Enabled Devices

(~150’ Range)

Place your PHS300 anywhere in your home or office for the best signal

Share your mobile broadband connection with all your WiFi enabled devices

such as:

laptops, desktop PCs, printers, VoIP phone, PDA, and more

WLAN

Signifies that the WiFi radio of the router is “On”. Blinking indicates traffic.

NETWORK

CONNECTION

Indicates that recognizable cellular device is connected to the router.

Red

Connection Not Made

Orange

Connection is Negotiating

Green

Connection is Established

LED Status Lights

POWER

Signifies the PHS300 power level.

Red

Battery Charge is Very Low

Orange

Plugged into Wall Power, Internal Battery is Charging

Green

Plugged into Wall Power, Internal Battery is Fully Charged

or

Operating Remotely on Fully Charged Internal Battery

WLAN

NETWORK

CONNECTION POWER

Finding Your Password and Network Name

MAC

ADDRESS

Media Access Control Address (MAC Address)

is a unique identifier assigned to the PHS300

Your default password for your PHS300 is the

last six characters of the MAC Address

and can be found on the back of the unit.

SSID

Service Set Identifier (SSID) is used to identify

your wireless network name.

Your default Network Name will be

PHS-xxx

You can change the name of your Network in

the Setup Wizard.

SERIAL

NUMBER

When you register your product online, you will

be asked for your Serial Number.

RESET

BUTTON

If you need to do a factory reset, consult the

CradlePoint Knowledge Base for instructions.

EXTEND YOUR

BATTERY LIFE

Turn your PHS300

OFF

when not in use for best battery performance

PHS-300

PHS-300

PHS-300

MAC: 00304402518b

Connecting To The Router
