64
NX509
English
INSTAL
LATIO
N
MAN
UAL
9. WIRE CONNECTION
Radio antenna jack
Connect to the AUX1 audio/
video input terminal.
or
iPod
Connector cable
(included in your
iPod)
Connector cable
(CCA-723)
iPod with video
Refer to the following page.
Gray
Purple
Gray
Green
Black
Red
White
Red
White
Red
White
Yellow
Yellow
White
Red
Yellow
Right
Left
Right
Left
Right
Left
Right
Left
Rear audio
output terminal
Subwoofer output
terminal (MONO 2ch)
Video output terminal
(2-Zone audio
output terminal)
AUX1 audio input
terminal
Rear Vision Camera terminal
4-Channel Amplifier
Rear Monitor
Wireless Headphone
VTR etc.
USB terminal
Red
White
Black
GPS antenna
jack
Aux2 audio input terminal
• Use the AUX1 audio input when you
connect your iPod.
• Connect the optional adaptor (BLT370)
when you use your Bluetooth cellular
phone.
Black
Black
AUX2 video input terminal
Connect to the AUX2 audio
input terminal.
Red
AUX1 video input terminal
Front audio
output terminal
Yellow
Steering wheel
remote control
terminal
CeNET
terminal
